This article discusses the need for improved health checks in vmauth to enhance high availability (HA) and failover capabilities. Currently, vmauth lacks the ability to actively monitor the health of its backend servers. When a backend becomes unavailable, vmauth continues to attempt connections, leading to service disruptions. Implementing L3/L4 health checks would allow vmauth to detect unhealthy backends and automatically redirect traffic to healthy ones, ensuring uninterrupted service.

The Problem: Lack of Backend Health Monitoring in vmauth

Currently, vmauth does not actively monitor the health of its backend servers. This can lead to problems in high-availability (HA) setups. Consider a scenario where you have configured vmauth with multiple backend URLs for the same service. The configuration below illustrates a simple setup with two vtsingle instances:

unauthorized_user:
  url_map:
  - load_balancing_policy: first_available
    src_paths:
    - /select/.*
    url_prefix:
    - http://vtsingle-cl1:10428
    - http://vtsingle-cl2:10428

In this configuration, vmauth is configured to use vtsingle-cl1 as the primary backend and vtsingle-cl2 as a secondary backend. The expectation is that if vtsingle-cl1 becomes unavailable, vmauth will automatically failover to vtsingle-cl2. However, without proper health checks, this failover does not occur seamlessly.

When vtsingle-cl1 is powered off, vmauth continues to attempt connections to it, resulting in errors and service disruptions. The logs show that vmauth repeatedly tries to proxy requests to the unavailable backend, leading to context cancellation errors. Crucially, it reports that all backends are unavailable, even though vtsingle-cl2 is still operational. This highlights the critical need for vmauth to actively monitor the health of its backends and avoid attempting connections to those that are down.

Proposed Solution: Implementing L3/L4 Health Checks

To address the lack of backend health monitoring, it is proposed that vmauth be enhanced with L3/L4 health checks. These checks would allow vmauth to proactively detect unavailable backends and remove them from the load balancing rotation. This would ensure that traffic is only directed to healthy backends, improving the overall reliability and availability of the system.

L3 Health Checks (ICMP)

L3 health checks, such as those using ICMP (ping), can be used to verify the network reachability of backend servers. vmauth could periodically send ICMP packets to each backend and consider a backend as unhealthy if it does not receive a response within a specified timeout. This would allow vmauth to quickly detect servers that are completely down or experiencing network connectivity issues.

L4 Health Checks (TCP Port Availability)

L4 health checks, on the other hand, would verify the availability of the TCP port on which the backend service is running. vmauth could attempt to establish a TCP connection to the backend's port and consider the backend as unhealthy if the connection fails or times out. This type of check is more specific than L3 checks, as it verifies that the service is not only reachable but also listening on the expected port.

By combining L3 and L4 health checks, vmauth can gain a comprehensive view of the health of its backends and make informed decisions about where to route traffic. This would significantly improve the failover capabilities of vmauth and ensure that services remain available even when some backends are down.

Alternatives Considered

An alternative configuration was attempted, but it did not solve the problem. This configuration involved using different URL prefixes for each backend and setting retry_status_codes. However, this approach did not prevent vmauth from attempting connections to unavailable backends.

unauthorized_user:
  url_map:
  - load_balancing_policy: first_available
    src_paths:
    - /select/.*
    url_prefix:
      - http://localhost/cl1/
      - http://localhost/cl2/
    retry_status_codes: [500, 502]
  - src_paths:
      - /cl1/.*
    drop_src_path_prefix_parts: 1
    url_prefix:
      - http://vtsingle-cl1:10428
  - src_paths:
      - /cl2/.*
    drop_src_path_prefix_parts: 1
    url_prefix:
      - http://vtsingle-cl2:10428

The issue with this configuration is that vmauth still relies on the backend to return a 500 or 502 error code to trigger a retry. If the backend is completely down, vmauth will not receive any response, and the retry mechanism will not be activated. This further emphasizes the need for proactive health checks that can detect unavailable backends before attempting to send traffic to them.

Benefits of Implementing Health Checks

Implementing L3/L4 health checks in vmauth would provide several benefits, including:

  • Improved High Availability: By automatically detecting and removing unhealthy backends, vmauth can ensure that traffic is always routed to healthy instances, minimizing downtime and service disruptions.
  • Reduced Error Rates: Health checks would prevent vmauth from attempting connections to unavailable backends, reducing the number of errors and improving the overall user experience.
  • Simplified Troubleshooting: With health checks in place, it would be easier to identify and diagnose backend issues, as vmauth would provide clear indications of which backends are unhealthy.
  • Enhanced Scalability: Health checks would enable vmauth to dynamically adjust its load balancing strategy based on the health of the backends, allowing it to scale more effectively.

Conclusion

In conclusion, the addition of L3/L4 health checks to vmauth is crucial for enhancing its high availability and failover capabilities. Without these checks, vmauth can continue to attempt connections to unavailable backends, leading to service disruptions and a degraded user experience. By proactively monitoring the health of its backends, vmauth can ensure that traffic is always routed to healthy instances, improving the overall reliability and scalability of the system. This enhancement would be particularly beneficial in environments where vmauth is used to protect critical services that require high uptime.

To learn more about implementing health checks, you can explore resources available on HAProxy's health check documentation. This will give you more insights into how health checks are implemented in production environments and the best practices involved.
